Pick and place test application with line gantry

Pick-and-Place Test with igus Linear Portal: Precision and Versatility

A Pick-and-Place test, conducted by rbtx for a client, showcased the efficiency of customized automation solutions using the igus linear portal. The process began with vacuum technology, which securely picked up a plastic disc to ensure reliable handling. The disc was then precisely positioned, demonstrating the high accuracy required in production workflows. In the final step, the positioned disc was pressed in using an aluminum profile attached next to the gripper, highlighting the system’s adaptability to include additional functional components.

What is the Application?

The test automates picking, positioning, and pressing of plastic discs, demonstrating its capabilities for repetitive and precise tasks in modern manufacturing.

What are the Advantages of the Solution?

• High Precision: Ensures reliable disc positioning for downstream tasks.

• Customizable Design: Integrates additional components like aluminum profiles.

• Optimized Efficiency: Automates complex processes, reducing manual intervention.

What are the Advantages of the Robot?

The igus linear portal delivers the following benefits:

• Secure Handling: Vacuum technology prevents accidental drops or misalignment.

• Versatility: Handles varied tasks with tailored components.

• Consistency: Reliable operation ensures repeatability during mass production.

Transforming Manufacturing with igus Linear Portals

This Pick-and-Place test demonstrates rbtx's ability to design customized automation solutions using igus linear systems. The seamless integration of precise handling and additional functional components reveals the versatility and efficiency of automated systems, paving the way for optimized workflows in modern manufacturing processes.
